Description
The AIO (All‑In‑One) series offers a compact, integrated solution—housing filtration chambers, overflow, and return within the aquarium for clean, minimalist setup. Ideal for both beginner and experienced aquarists, AIO tanks range from 20 to 65 gallons and come equipped with adjustable nozzle returns, filter socks, carbon pellets, ceramic rings, and in smaller models, included pumps. Built with sturdy aluminum‑framed cabinetry and sleek white/black/aspen finishes, they deliver performance and style in one package
The Display & Filtration
Newbie or Pro
The AIO was designed so you can keep more in your aquarium with less. Available from 20 through 65 gallons, the AIO delivers an aquatic environment for novice and professional aquarium keepers.
Adjustable Nozzle return allow for precise water agitation.
Ideal for novice and professional aquarium keepers
The unique filtration and baffle system forces the water to travel through the filter socks and then flow into chambers adequately sized for multiple types of filtration media.
Filtration media is included to keep your water clear and polished.
The Cabinetry
Strength & Stability
Waterbox furniture is designed to elevate your living spaces with our first in class cabinetry and finishes. Available in white, black, or aspen.
Engineered to stand the test of time.
PVC Laminated OSB panels easily withstand the weight and humidity of your aquarium system.
Adjustable Leveling Feet provide easy and effective way to ensure your aquarium is level, front to back and side-to-side.
Technical Specifications
Product ModelAIO 20 CubeAIO 25 PeninsulaAIO 35.2AIO 50.3AIO 65.4
Aquarium
Dimensions (LxWxW)
450 x 450 x 400mm
600 x 400 x 400mm
600 x 500 x 450mm
900 x 500 x 450mm
1,200 x 500 x 450mm
17.7″ × 17.7″ × 15.7″
23.6″ × 15.7″ × 15.7″
23.6″×19.7″×17.7″
35.4″×19.7″×17.7″
47.2″×19.7″×17.7″
Tank Volume
76 L
90 L
125 L
186 L
249 L
20.0 gals
23.7 gals
33 gals
49.1 gals
65.8 gals
Glass Thickness
6mm (1/4″)
6mm (1/4″)
8mm (5/16″)
10mm (2/5″)
10mm (2/5″)
Aquarium Weight
17.5 kg/39 lbs
21 kg/46 lbs
33 kg/73 lbs
52 kg/115 lbs
56 kg/123 lbs
Front & Sides
Ultra-clear Low Iron glass (front and sides)
Transmittance
91%
Filtration Compartment(Int. Dimensions)
438 x 80 x 387mm
388 x 80 x 387mm
584 x 120 x 435mm
880 x 120 x 433mm
1180 x 120 x 433mm
17.2″ × 3.1″ ×15.2″
15.3″ × 3.1″ × 15.2″
23″ × 4.7″ × 17.1″
34.6″ × 4.7″ × 17″
46.5″ × 4.7″ × 17″
Filter Sock Chamber(Int. Dimensions)
80 x 80 x 387mm
80 x 80 x 387mm
81 x 120 x 435mm
81 x 120 x 433mm
161 x 120 x 433mm
3.1″ × 3.1″ × 15.2″
3.1″ × 3.1″ × 15.2″
3.2″ × 4.7″ × 17.1″
3.2″ × 4.7″ × 17″
6.3″ × 4.7″ × 17″
Media/Skimmer Chamber(Int. Dimensions)
200 x 80 x 387mm
173 x 80 x 387mm
101 x 120 x 435mm
154 x 120 x 433mm
150 x 120 x 433mm
7.9″ × 3.1″ ×15.2″
6.8″ ×3.1″ × 15.2″
4″×4.7″×17.1″
6.1″×4.7″×17″
5.9″×4.7″×17″
Pump Chamber(Int. Dimensions)
80 x 118 x 387mm
80 x 95 x 387mm
140 x 120 x 435mm
300 x 120 x 433mm
221.5 x 120 x 433mm
3.1″ × 4.6″ × 15.2″
3.1″ × 3.7″ × 15.2″
5.5″×4.7″×17.1″
11.8″×4.7″×17″
8.7″×4.7″×17″
Directional Nozzle(Thread Size)
1 x M14 (14mm), Flare
1 x M20 (20mm), Y-shape
2 x M20 (20mm), Y-shape
Return Hose
lD: 12mm OD: 16mm
lD: 12mm OD: 16mm
lD: 18mm OD: 24mm
Pump
AP-1500
n.a.
Pump Flow
1000 LPH/265 GPH
n.a.
EVA Mat
x 1
x 1
Filtration
225 Micron Filter Socks
1 x 70mm/2.75″ FELT
2 x 70mm/2.75″ FELT
2 x 70mm/2.75″ FELT
4 x 70mm/2.75″ FELT
Filtration Sponge
x 2
x 4
x 4
x 4
Activated Carbon
150g
2 x 150g
2 x 150g
3 x 150g
Ceramic Ring
300g
2 x 300g
2 x 300g
3 x 300g
Cabinet(optional)
Cabinet Model
PB 1818
PB 2416
OSB 2420
OSB 3620
OSB 4820
Dimensions
450 x 450 x 810mm
600 x 400 x 810mm
600 x 500 x 900mm
900 x 500 x 900mm
1,200 x 500 x 900mm
17.7″×17.7″×31.9″
23.6″×15.7″×31.9″
23.6″×19.7″×35.4″
35.4″ × 19.7″ × 35.4″
47,2″ × 19.7″ × 35.4″
Material
18mm PVC Laminated Wood Oriented Strand Board
Door(s) & Side Panels
Bottom Panels
Back Panels
Cabinet Weight
–
–
–
–
–
Color
White/Black/Aspen
WHT-White, BLK-Black, ASP-Aspen
