Description
MARINE X
Product Model
MARINE X 60.2
MARINE X 90.3
MARINE X 110.4
MARINE X 110.4 PENINSULA
System
Height with Cabinet
1,400mm
/55.1″
1,450mm
/57.1″
1,450mm
/57.1″
1,450mm
/57.1″
Total Volume with RO
211 L/55.6 gals
342 L/90.2 gals
418 L/110.5 gals
418 L/110.5 gals
Total System Weight
87 kg/192 lbs
130 kg/287 lbs
173 kg/381 lbs
Display
Tank
Tank Dimensions
600 x 500 x 500mm
900 x 500 x 550mm
1,200 x 500 x 550mm
1,200 x 500 x 550mm
23.6″ × 19.7″ × 19.7″
35.4″ × 19.7″ × 21.7″
47.2″ × 19.7″ × 21.7″
47.2″ × 19.7″ × 21.7″
Glass Thickness
10mm (2/5″)
12mm (1/2″)
12mm (1/2″)
12mm (1/2″)
Aquarium Volume
136 L/36 gals
224 L/59.3 gals
301 L/79.6 gals
301 L/79.6 gals
Aquarium Weight
47 kg/104 lbs
54 kg/119 lbs
78 kg/172 lbs
78 kg/172 lbs
Glass Material
Ultra-clear Low Iron glass (front and sides)
Transmittance
91%
In-cabinet
Sump
Dimensions
510 x 410 x 380mm
800 x 410 x 380mm
800 x 410 x 380mm
20.1″ × 16.1″ × 15″
31.5″ × 16.1 × 15″
31.5″ × 16.1 × 15″
Sump Volume
74 L/19.6 gals
117 L/31 gals
117 L/31 gals
Sump Weight
13 kg/29 lbs
38 kg/84 lbs
38 kg/84 lbs
Glass Thickness
6mm (1/4″)
6mm (1/4″)
6mm (1/4″)
Skimmer Chamber
(Int. Dimensions)
308 x 258mm
388 x 343mm
363 x 398mm
12.1″ × 10.2″
15.3″ × 13.5″
14.3″ × 15.7″
Pump Chamber
(Int. Dimensions)
140 x 210mm
210 x 150mm
220 x 163mm
5.5″ × 8.3″
8.3″ × 5.9″
8.7″ × 6.4″
RO Reservoir
(Int. Dimensions)
140 x 183 x 359mm
210 x 243 x 359mm
150 x 398 x 374mm
5.5″ × 7.2″ × 14.1″
8.3″ × 9.6″ × 14.1″
5.9″ × 15.7″ × 14.7″
RO Volume
9.2 L/2.4 gals
18.3 L/4.8 gals
22.3 L/5.9 gals
Plumbing
Main Drain
DN20 (ID: 20mm OD: 25mm)
DN25 (ID: 25mm OD: 32mm)
DN25 (ID: 25mm OD: 32mm)
Emergency Overflow
DN20 (ID: 20mm OD: 25mm)
DN25 (ID: 25mm OD: 32mm)
DN25 (ID: 25mm OD: 32mm)
Pump Return
DN20 (ID: 20mm OD: 25mm)
DN20 (ID: 20mm OD: 25mm)
DN20 (ID: 20mm OD: 25mm)
Return Hose
lD: 18mm OD: 24mm
lD: 18mm OD: 24mm
Nozzle(s) (Thread Size)
2 x M20 (20mm)
2 x M20 (20mm)
Filtration
225 Micron Filter Socks
1 x 105mm/4″ FELT
2 x 105mm/4″ FELT
2 x 105mm/4″ FELT
Filter Sock Silencers
1 x 105mm/4″
2 x 105mm/4″
2 x 105mm/4″
Interchangable with Roller Filter
YES
YES
YES
Cabinet
Cabinet Model
OSB 2420
OSB 3620
OSB 4820
OSB-D4820
Cabinet Ext. Dimensions
600 x 500 x 900mm
900 x 500 x 900mm
1,200 x 500 x 900mm
1,200 x 500 x 900mm
23.6″ × 19.7″ × 35.4″
35.4″ × 19.7″ × 35.4″
47.2″ × 19.7″ × 35.4″
47.2″ × 19.7″ × 35.4″
Cabinet Int. Dimensions
564 x 464 x 764mm
864 x 464 x 764mm
1,128 x 464 x 764mm
n.a.
22.2″ × 18.3″ × 30.1″
34″ × 18.3″ × 30.1″
44.4″ × 18.3″ × 30.1″
Sump Compartment
(Int. Dimensions)
n.a.
n.a.
n.a.
880 x 464 x 764mm
34.6″ × 18.3″ × 30.1″
Cabinet Material
18mm PVC Laminated Wood Oriented Strand Board
18mm PVC Laminated Wood Oriented Strand Board
Cabinet Weight
27 kg/60 lbs
38 kg/84 lbs
57 kg/126 lbs
Cabinet Color
WHT-White, BLK-Black, ASP-Aspen
WHT-White, BLK-Black
MARINE EX
Product Model
MARINE EX 60.2
MARINE EX 90.3
MARINE EX 110.4
System
Height with Cabinet
1,400mm/55.1″
1,450mm/57.1″
1,450mm/57.1″
Total Volume with RO
207 L/54.7 gals
337 L/89gals
414 L/109.3 gals
Total System Weight
–
–
–
Display
Tank
Tank Dimensions
600 x 500 x 500mm
900 x 500 x 550mm
1,200 x 500 x 550mm
23.6″×19.7″×19.7″
35.4″×19.7″×21.7″
47.2″×19.7″×21.7″
Glass Thickness
10mm (2/5″)
12mm (1/2″)
12mm (1/2″)
Aquarium Volume
136 L/36 gals
224 L/59.3 gals
301 L/79.6 gals
Aquarium Weight
37.7 kg/83 lbs
69.4 kg/153 lbs
85.4 kg/188 lbs
Glass Material
Ultra-clear Low Iron glass (front and sides)
Transmittance
91%
Overflow Type
Acrylic External Overflow
In-cabinet
Sump
Dimensions
510 x 410 x 380mm
800 x 410 x 380mm
20.1″ × 16.1″ × 15″
31.5″ × 16.1 × 15″
Sump Volume
71 L/18.7gals
113 L/29.7 gals
Sump Weight
9 kg/20 lbs
12 kg/26 lbs
Acrylic Thickness
5mm (3/16″)
5mm (3/16″)
Skimmer Chamber
(Internal Dimensions)
265 x 245mm
380 x 303mm
10.4″×9.7″
15″×11.9″
Skimmer Chamber
(Cutout Dimensions)
250 x 230mm
367 x 287mm
9.8″×9.1″
14.4″×11.3″
Pump Chamber
(Internal Dimensions)
195 x 225mm
225 x 225mm
7.7″×8.9″
8.9″×8.9″
Pump Chamber
(Cutout Dimensions)
162 x 211mm
210 x 190mm
6.4″×8.3″
8.3″×7.5″
RO Reservoir
(Cutout Dimensions)
184 x 146mm
212 x 146mm
7.2″×5.7″
8.3″×5.7″
RO Reservoir
(Internal Dimensions)
195 x 160mm
225 x 160mm
7.7″×6.3″
8.9″×6.3″
RO Volume
11.3 L/3 gals
13.1 L/3.5 gals
Plumbing
Main Drain
DN20 (ID: 20mm OD: 25mm)
DN25 (ID: 25mm OD: 32mm)
Emergency Overflow
DN20 (ID: 20mm OD: 25mm)
DN25 (ID: 25mm OD: 32mm)
Pump Return
DN20 (ID: 20mm OD: 25mm)
Nozzle(s) (Thread Size)
2 x M20 (20mm)
Filtration
225 Micron Fileter Socks
1 x 105mm/4″ FELT
2 x 105mm/4″ FELT
Filter Sock Silencers
1 x 105mm/4″
2 x 105mm/4″
Cabinet
Cabinet Model
OSB 2420
OSB 3620
OSB 4820
Cabinet Dimensions
600 x 500 x 900mm
900 x 500 x 900mm
1,200 x 500 x 900mm
23.6″ × 19.7″ × 35.4″
35.4″ × 19.7″ × 35.4″
47.2″ × 19.7″ × 35.4″
Sump Compartment
(Int. Dimensions)
524 x 468 x 813mm
824 x 448 x 813mm
1,124 x 440 x 813mm
20.6″ × 18.4″ × 32″
32.4″ × 17.6″ × 32″
44.3″ × 16.5″ × 32″
Cabinet Framework
18mm PVC Laminated Wood Oriented Strand Board
Door & Side Panels
Bottom Panels
Back Panels
Cabinet Weight
–
–
–
Cabinet Color
WHT-White, BLK-Black, ASP-Aspen
